Size7 inch
-
Resolution1024(RGB)X600
-
Active Area154.08X85.92mm
-
Outline Size50.50 x 69.70 x 3.85 mm
-
InterfaceLVDS
-
Working Temperature-20°C-70°C
-
Strorage Temperature-30°C-80°C
-
Brightness500cd/m2
ROHS certificated 7 inch TFT-LCD Screen with Resolution 1024(RGB)X600 / LVDS Interface / Brightness 500
1. General Specifications
ORD-TFT070CE014 is a TFT-LCD module. It is composed of a TFT-LCD panel,
driver IC, FPC, a back light unit. The 7 display area contains 1024 x 600 pixels
and can display up to 16M colors. This product accords with RoHS
.
LCD Type : TFT -
Display color : 16M
Viewing Direction : 12 O’Clock
Operating temperature : -20~+70 ℃
Storage temperature : -30~+80 ℃
Module size : 165*100*5.7 mm 2
Active Area(W×H) : 154.21x85.92 mm
Number of Dots : 1024×RGB×600 dots
Power Supply Voltage : 3.3 V
Backlight :27-LEDs (white) pcs
Brightness(LCM) : 500 CD/M^2
Data Transfer : LVDS
2.Mechanical Drawing
