넳 넲
  • Size
    0.71 inch
  • Resolution
    48(RGB)X64
  • Active Area
    10.54X14.7mm
  • Outline Size
    13.9 x 22 x 1.2 mm
  • Working Temperature
    -40°C-90°C
  • Interface
    IIC
  • Strorage Temperature
    -40°C-90°C
  • Brightness
    80cd/m2

Basic Specifications



Display Mode: Passive Matrix

Display Color: Mono Chrome(white)

Drive Duty: 1/64 Duty

Resolution: 48*64

Panel Size:13.9*22*1.2(mm)

Active Area: 10.54*14.7(mm)

Pixel Pitch: 0.20*0.21(mm)

Pixel Size: 0.22*0.23(mm)



Mechanical Drawing

0.71incholedcanshu3
